Slag dryer
Discription of slag dryer
1)TOP slag dryer
2)hot sale in Asia,Middle East,South America
3)high dry capacity low energy consum
Application of slag dryer
The slag dryer has been verified by the commercial plant lifting flights with optimal design make the head and mass transfer more complete,increase evaporation rate and productivity, the cylinder is flanged connection,with good alignment,convenient for transportation and installation.It is widely used in drying big particles, heavy particles in building material, chemical engineering, metallurgy , and cement, such as mining area, cinder of blast furnace, coal, coal powder, phosphate fertilizer and clay.
Features of slag dryer
the structure is reasonable; the production capacity is high; the power consumption is low. Application capability to different characters of materials is high. The operation is stable, the operation fee is low, and the uniformity of product drying is good.
Technical Specification of slag dryer
|
Item Specification |
Shell inner dia. | Shell length |
Slope 0 |
Rotating speed r/min |
Flow |
Motor power kw |
Output t/h | Inlet moisture | Outlet moisture | Inlet hot air temp. | Outlet hot air temp. |
Weight t |
| φ1.5×12m | 1500 | 12000 | 2.0 | 3.4 | 15 | ∼4 | 15∼10% | 1∼30% | 800∼7000c | 150∼900c | 19.6 | |
| φ1.8×15m | 1800 | 15000 | 2.0 | 4.04 | 18.5 | ∼6.5 | 25 | |||||
| φ2.2×14m | 2200 | 14000 | 2.0 | 3.68 | 37 | ∼11 | 44 | |||||
| φ2.2×18m | 2200 | 18000 | 2.0 | 2.9 | 37 | ∼12 | 48 | |||||
| φ2.4×18m | 2400 | 18000 | 2.0 | 3.27 | 45 | ∼16 | 56 | |||||
| φ2.6×24m | 2600 | 24000 | 2.5 | 3.2 | 55 | ∼22 | 72.5 | |||||
| φ2.8×24m | 2800 | 24000 | 2.0 | 3.4 | 55 | 20-40 | 87 | |||||
| φ3.0×20m | 3000 | 20000 | 2.29 | 3.1 | 75 | 25-60 | 105 | |||||
| φ3.0×25m | 3000 | 25000 | 2.29 | 3.2 | 75-90 | 35-80 | 125 | |||||
| φ3.2×25m | 3200 | 25000 | 2-2.29 | 4.14 | 90-132 | 60-150 | 155 | |||||
| φ3.4×28m | 3400 | 28000 | 2-2.29 | 3-4.1 | 110-132 | 70-150 | 162 | |||||
| φ3.6×28m | 3600 | 28000 | 2.0 | 2.6-4 | 160-200 | 80-155 | 168 |
