Pendulum feeder
Discription of Pendulum feeder
It is suitable for concentrating coal chemical industryand other departments, makes the grain delivery to various set of accepting the material from the store chute by the filter. The pendulum feeder is not suitable for delivering the dry power of the too big material or else, it may appear the fly-ash pollution or the jam of the output
Technical parameters of Pendulum feeder
| Product name | Pendulum feeder | Pendulum feeder | ||
| Product size | 400*400 | 600*600 | ||
| Swing t imes(times/min) | 47 | 45.8 | ||
| Output size(mm) | Width | 400 | 600 | |
| Height | 400 | 600 | ||
| Swing journey(mm) | 0-170 | 0-220 | ||
| Max feeding size(mm) | 35 | 50 | ||
| Capacity(t/h) | 0-12 | 3-25 | ||
| Motor | Type | Y90S-4 | Y100L-4 | |
| Power(kw) | 1.1 | 2.2 | ||
| Total weight(kg) | 269 | 558 | ||
