Brief Introduction of Rotary Drum Granulator:

Rotary Drum Agglomerator / Granulator (also known as balling drums or rotary granulators) are very versatile pieces of equipment that can process a wide array of materials. Rotary Drum Granulator is typically used for high capacity applications and usually requires some type of recycle depending on the product specifications. Drum Granulators are used when an Agglomeration - Chemical Reaction Process is required.

Typical applications of a Rotary Drum Granulator include:

Agglomeration involving Chemical Reactions where the feed component(s) consist of reactive liquids or gases. The liquid and/or gas can be added into the bed of material to get a complete reaction and contain or reduce any emissions that may be generated. Many inorganic fertilizers are produced in this manner.
Conversion of fine Mineral Ores into easy to handle agglomerates or balls for further processing. Iron ore, copper ore, and gold ore are a few examples.
Rotary Drum Granulator where the only feed or the majority of the feed is a Liquid or Melt such as urea granulation.
Coating of finished products by spraying a liquid onto the bed of material.
Mixing drums that can mix multiple solids and/or liquids.
Specialty Applications like a combination Granulation-Cooling Drum.
TAIDA's custom designs can accommodate the addition of other equipment and accessories such as pipe reactors, discharge trommel screens, liners (rubber or metal), spray bars, and spargers. If you need to control emissions or dusting, TAIDA's discharge breeching design makes capturing these materials easy so you don't have to worry about contamination of the surrounding area.
As the one of the key equipments in fertilizer industry, rotary drum granulator is applicable to cold, heat, and guniting and ammoniated granulation and big scale fertilizer production of high, medium and low concentration. The cylinder body adopts special stainless steel or rubber plate lining structure. It can remove scar and peel burl automatically It has the advantages of high intensity of granule, high production, erosion proof, abrasion proof, low energy consumption, long service life, convenient operation and maintenance etc.Remark: If the formulation, process and raw material are different, it will affect the yield, grain rate and the diameter of the grain.

Technical parameters of Rotary Drum Granulator

Specification(m)

Shell

Capacity(t/h)

Power(kw)

I.D.(mm)

Length(mm)

Slope(°)

Rev(r/min)

Ø1.4×4

1400

4000

2.5

15.05

5

11

Ø1.6×6

1600

6000

2.5

12

7

15

Ø1.8×6

1800

6000

2.5

11.5

8

15

Ø2.0×7

2000

7000

2.5

10.8

14

30

Ø2.2×8

2200

8000

2.5

10.85

20

37

Ø2.4×8

2400

8000

2.5

9.6

25

55

Ø2.8×8

2800

8000

1.5

6.5

35

90
