double roll crusher
double-roll crusher Introduction:
used for middle crushing and fine crushing of all kinds of ore and rocks under mid-hardness in mineral dressing, chemistry, cement, building materials and other industrial sections
double-roll crusher Characteristics:
Reliable operation, easy maintainence, low operating costs, adaptable feed granularity.
double-roll crusher Technical specification:
| Type | 2PG400×250 | 2PG610×400 | 2PGC450×500 | 2PGC600×750 | ||
| Roller diameter(mm) | 400 | 610 | 450 | 600 | ||
| Roller length(mm) | 250 | 400 | 500 | 750 | ||
| Max marerial-in size(mm) | ≤25 | ≤85 | ≤100—200 | ≤300—600 | ||
| Material-out size(mm) | 2—8 | 10—30 | 25—100 | 50—125 | ||
| capacity(t/h) | 5—10 | 13—40 | 20—55 | 60—125 | ||
| Roller number | 2 | 2 | 2 | 2 | ||
| Roller speed (r/min) | 180 | 75 | 64 | 50 | ||
| Pure weight | 1.1 | 3.5 | 3.8 | 8.34 | ||
| Overall size(l×w×h)(mm) | 1215×834×830 | 2235×1722×810 | 2260×2200×766 | 2780×3065×1310 | ||
| Assorted motor | Type | Y160L—6 | Y225M—6 | Y160L--8 | Y180L--8 | Y225M—8 |
| power(kw) | 11 | 30 | 7.5 | 11 | 22 | |
