Mesh-belt Dryer

Mesh-belt dryer is a continuous penetrating flow drying equipment applied for drying pieces strip and particles state materials with good ventilation. The machine is suitable for the materials such as food, fruit, marine products, dewatering vegetable, herbal medicine of traditional Chinese medicine and others, for which the water contents are high and high drying temperature is not allowed. The machine owns the advantages, of fast drying speed, high evaporation capacity and good product quality. The de-watered filtered cake state paste material should be made into particles or strips before drying process.

        The materials are uniformly distributed on the mesh-belt by the material feeder. The mesh-belt generally adopts 12-60 mesh stainless steel mesh and it is drawn by a transmission device and move inside the dryer . The dryer is composed of several sections. For each section, the hot air is circulated separately. Part of exhausted gas is exhausted by a special moisture exhaust blower. The waste gas is controlled by an adjustment valve. The hot air passes through the mesh-belt covered with bring water material away. The mesh-belt moves slowly, running speed can be freely adjusted according to the material property. The final products after the drying process will fall into the material collector continuously. The top and low circulation units can be freely equipped according to the user's requirements. The number of section might be selected according to the production demands

Technical specification

Items	Model
	DW-25	DW-35	DW-45
Heating unit	Double rooms	Three rooms	Five rooms
Material processing area (m2)	25	35	55
Steam working pressure (Mpa)	0.4～0.5	0.4～0.6	0.4～0.7
Drying cycle (minute)	22～220	45～450	60～600
Water evaporation capacity (kg/h)	70～220	100～330	170～550
Power (kw)	12.78	15.78	24.78
Weight (kg)	6500	9500	12000
Overall dimensions (l*w*h)	9875×2408×3385	11475×2408×3385	14675×2408×3385
