monocular-cooler
Monocular Cooler
Monocular cooling machine is the main marching equipment for rotary kiln production system or rotary dryer system, its structure is simple, performance stable and operation reliable. The waste gas produced by heat exchange will be imported into rotarykiln so as to improve the thermal efficiency of the whole system.
Type (mm) |
Indiclination (%) |
rotation speed (r/min) |
Output (t/h) |
motor power (kw) |
Dimension (mm) |
Weight（kg） |
TDLQΦ800×12000 |
4 |
4.98 |
0.4-0.8 |
5.5 |
12300×2020×1920 |
7455 |
TDLQΦ1000×12000 |
5 |
5.03 |
1.0-2.0 |
7.5 |
12000×2121×1903 |
12580 |
TDLQΦ1200×12000 |
4 |
5.03 |
2.0-3.0 |
4 |
12000×2277×2318 |
15986 |
TDLQΦ1200×15000 |
4 |
5.99 |
2.5-3.5 |
11 |
15000×2277×2318 |
18732 |
TDLQΦ1500×12000 |
3.5 |
4.01 |
3.5-4.8 |
15 |
12000×2935×2910 |
20644 |
TDLQΦ1500×15000 |
3.5 |
4.01 |
3.8-5.2 |
15 |
15000×2935×2910 |
21976 |
TDLQΦ1800×18000 |
3.5 |
3.5 |
5.0-7.1 |
22 |
18000×3510×3580 |
58600 |
TDLQΦ2000×20000 |
3.5 |
3.44 |
8.0-10 |
30 |
20000×3810×3820 |
61100 |
TDLQΦ2000×22000 |
3.5 |
3.44 |
8.5-10.5 |
30 |
22000×3810×3820 |
62632 |
TDLQΦ2200×22000 |
3.5 |
3.44 |
10-12.5 |
30 |
20000×4110×4120 |
88610 |
TDLQΦ2500×22000 |
3.5 |
3.52 |
11-14 |
55 |
24830×4680×6020 |
108780 |
